waveshare 5inch HDMI LCD Resistive Touch Screen LCD (B), 800x480 Resolution, Support All Versions of Raspberry Pi,Windows 10/8.1/8/7, BB Black, as Well as General Desktop Computers
Product details
| Management number | 209105610 | Release Date | 2026/03/29 | List Price | $19.20 | Model Number | 209105610 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Features 800x480 high hardware resolution Resistive touch control Supports popular mini PCs such as Raspberry Pi, BB Black, as well as general desktop computers When works with Raspberry Pi, supports Raspbian/Ubuntu/Kali/Retropie/WIN10 IOT, driver free When work as a computer monitor, supports Windows 10/8.1/8/7, single touch, and driver free Backlight can be turned off to lower power consumption Note: to use the LCD with following mini-PCs, additional cables are required and should be purchased separately: Raspberry Pi Zero: HDMI cable, USB-type-A-receptacle-to-Micro-B-plug-cable BB Black: HDMI cable Supports all versions of Raspberry Pi Supports Raspbian, single point touch, driver free Supports Ubuntu / Kali / WIN10 IoT, single point touch, driver free Supports Retropie, driver free FAQ Why the LCD doesn't work with my Raspbian? To use the LCD with the Raspberry Pi official image, driver (SPI touch interface only) should be installed first. Please refer to the user manual. However, for the first testing, you may want to use our image directly (if provided). Which power supply should I use? It is recommended to use a 5V/3A power adapter for the Raspberry Pi other than USB connection, otherwise the Pi may failed to start up because the PC's USB port might have not enough power. For large size LCDs, say, 10inch diagonal or more, another stand-alone power adapter is also required to provide power to the LCD. For more info, please check the wiki page. Package Content 1.5inch HDMI LCD (B) x 1 2.HDMI cable x 1 3.HDMI to Micro HDMI Adapter x 1 4.USB type A plug to micro B plug cable x 1 5.Touch pen x 1 6.RPi screws pack (4pcs) x 1
- 800x480 high hardware resolution,5inch Resistive touch control screen. Backlight can be turned off to lower power consumption
- Supports popular mini PCs such as Raspberry Pi, BB Black, as well as general desktop computers. When works with Raspberry Pi, supports Raspbian/Ubuntu/Kali/Retropie/WIN10 IOT, driver free. When work as a computer monitor, supports Windows 10/8.1/8/7, single touch, and driver free .
- Note: to use the LCD with following mini-PCs, additional cables are required and should be purchased separately: Raspberry Pi Zero: HDMI cable, USB-type-A-receptacle-to-Micro-B-plug-cable. BB Black: HDMI cable
- Support all Versions of Raspberry Pi, Supports Raspbian, single point touch, driver free. Supports Ubuntu / Kali / WIN10 IoT, single point touch, driver free. Supports Retropie, driver free.
| Brand | waveshare |
|---|---|
| Color | Black |
| Voltage | 5 Volts |
| Model Name | RS2118 |
| Resolution | 800x480 |
| Screen Size | 5 Inches |
| Aspect Ratio | 1.66:1 |
| Display Type | LCD |
| Manufacturer | Waveshare |
| Model Number | LCD Display |
| Mounting Type | Desk Mount |
| Screen Finish | Glossy |
| Viewing Angle | 178 Degrees |
| Contrast Ratio | 2000:1 |
| Total Usb Ports | 1 |
| Has Color Screen | No |
| Native Resolution | 800 x 480 |
| Display Technology | LCD |
| Additional Features | Touchscreen |
| Hardware Connectivity | HDMI, USB |
| Connectivity Technology | HDMI, USB |
| Specific Uses For Product | Desktop |
| Display Resolution Maximum | 800x480 |
| Total Number of HDMI Ports | 1 |
| Number of Component Outputs | 1 |
