120 Plate Brazed Plate Heat Exchanger, stainless steel wort chiller homebrew chiller beer cooling coil(120 Different Side)
Product details
| Management number | 215032126 | Release Date | 2026/04/12 | List Price | $370.50 | Model Number | 215032126 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Product parameters：Type:Brazed Plate Heat ExchangerTap water interface: 20mm outer diameterHeating interface:25mm outer diameter Plates Number: 120Material:SUS 304 Stainless Steel, food gradeWeldIing Material: 99.9% CopperThread of Port A1,A2:1/2" BSPT MaleThread of Port B1,B2:3/4" BSPT MaleHeat Transfer Area/plate: 0.028 m2(0.30 ft2)Thickness of One Plate:0.25-0.35mmLiquid volume: 0.06L/channelConnection mode: the largest thread connection, the largest welding connectionHot water source: 1 inch for outer wire, 6 points for inner wire, tap water inlet: 4 points by default.Working Temperature:-160 to + 185 Below 50 plates: suitable for washing hands and face60-80 plates: suitable for kitchen washing dishes and dishes.100-120 plates: can support bathing, mainly depends on the heat source's ability to supply
- Material: Constructed from durable stainless steel for long-lasting performance
- Convenience: Immersion cooler features simple operation, easy installation, and effortless cleaning
- Design: Cooling coils rapidly chill wort, beer, and other liquids, achieving optimal cooling efficiency by matching water temperature
- Space: Compact footprint maximizes space utilization in brewing equipment
- After-sales: Should any issues arise, we will address them promptly
| Item Weight | 39.7 pounds |
|---|---|
| Manufacturer | BNLUKQTST |
| Item model number | BNLUKQTST |
| Package Dimensions | 0.39 x 0.39 x 0.39 inches |
